Main features
- Working time with 410W load: 0m 43s
- Output power: 410 Watts / 750 VA
- Rated output voltage: 230V
- Rated input voltage: 230V
- Input connection type: 4 IEC 60320 C13
- Cord length: 1.2 meters
Exit
- Maximum set power(W): 410 Watts / 750VA
- Output frequency (synchronized with the power grid): 50/60 Hz +/- 1 Hz Synchronized with the power grid
- Topology: Linear-interactive
- Type of voltage form: Step approximation of a sine wave
- Switching time: 6 ms typical : 10 ms maximum
Entrance
- Input frequency: 50/60 Hz +/- 5 Hz Auto detection
- Input voltage range during mains operation: 140 - 300V
- Number of power cables: 1
- Input power factor under full load: 0.63
Batteries and battery life
- Battery Type: Lead-acid battery
- Typical recharge time: 8 hours
- Rated battery voltage: 12 V
- Replaceable battery: RBC17
- Expected battery life (years): 3 - 5
Communication and administrative tools
- Control panel: LED display with indicators on line (mains operation) : on battery (battery operation)
- Beep: Signal to switch to battery operation mode : a special signal of battery depletion
Surge protection and noise filtering
- Burst energy Rating: 273joules
- Data Line Protection: Ethernet protection 10/100/1000 Base-T RJ45
Physical parameters
- Maximum height: 160MM, 16.0cm
- Maximum width: 120MM, 12.0cm
- Maximum depth: 355MM, 35.5cm
- Net weight: 5.4KG
- Gross weight: 5.9KG
- Dimensions of the transport package: 250x197x430MM
- Color: Black
Environmental Parameters
- Operating temperature: 0 - 40 °C
- Operating range of relative humidity: 0 - 95 (Non-condensing) %
- Operating range of altitude above sea level: 0 - 3000meters
- Storage temperature: -15 - 40 °C
- Storage relative humidity: 0 - 95 (Non-condensing) %
- Storage altitude above sea level: 0 - 3000meters
- Acoustic noise level at a distance of 1 m from the surface of the device: 40.0dB(A)
- Protection class: IP20
Accordance
- Compliance with the requirements: CB, CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2
Standard warranty: 2 years for repair or replacement. The warranty period begins to be calculated from the date of sale, but no later than 6 months from the date of production.
