Output
- Max Configurable Power (Watts) - 900 Watts / 1.5kVA;
- Output Voltage - Distortion;
- Less than - 5 %;
- Output Frequency (sync to mains) - 50/60 Hz +/- 3 Hz Sync to mains;
- Other Output Voltages - 220 V, 240 V;
- Topology - Line interactive;
- Waveform type - Sine wave;
- Transfer Time - 6 ms typical : 10 ms maximum.
Input:
- Input frequency 50/60 Hz +/- 3 Hz Auto-sensing;
- Input voltage range for main operations - 170 - 300 Adjustable, 180 - 287V;
- Number of Power Cords - 1;
- Other Input Voltages - 220 V, 240 V
Batteries & Runtime:
- Battery type - Lead-acid battery;
- Typical recharge time - 3 hour(s);
- Replacement Battery - APCRBC157;
- Expected Battery Life (years) - 4 - 6;
- RBC Quantity - 1;
- Battery Charge Power (Watts) - 112 Watts.
Communications & Management:
- Interface Port(s) - RJ-45 Serial, USB;
- Control panel - Multifunction LCD status and control console.
Surge Protection and Filtering:
- Surge energy rating - 459Joules;
- Filtering - Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449.
Physical:
- Shipping weight - 31.91KG;
- Shipping Height - 251MM, 25.1CM;
- Shipping Width - 603MM, 60.3CM;
- Shipping Depth - 594MM, 59.4CM;
- Color;
- Black.
Environmental:
- Operating Temperature - 0 - 40 °C;
- Operating Relative Humidity - 0 - 95 %;
- Operating Elevation - 0 - 3048meters;
- Storage Temperature - (-15 - 45 °C);
- Storage Relative Humidity - 0 - 95 %;
- Storage Elevation - 0 - 15240meters;
- Audible noise at 1 meter from surface of unit - 46.0dBA;
- Online thermal dissipation - 90.0BTU/hr.
